DENTAL EQUIPMENTS

TECHNICAL SPECIFICATIONS:-
Binocular Tubes : Fixed Inclined at 45degree
Eye Pieces : 10x WF
Magnifications : 5 Step (4x, 6x, 10x, 16x & 25x)
Objective Lens : F=200mm / 250mm / 300mm / 400mm (Any One)
Field of View : 50mm
IPD Adjustment : 55mm to 75mm
Fine Focusing : Manual Fine Focusing by knob
Illumination : Through Fiber Optic Light Source 15V/150W twin Halogen Lamps
Light Intensity : 80,000 Lux max. at standard conditions
Field of Illumination : 70mm
Arm : Counter balanced pantographic arm with 320 degree rotation.
Vertical Range of Counter Balanced Arm : 250mm to 300mm
Floor Stand : Mobile floor stand on caster wheels for
easy handling and absolute stability.
Base : 600mm x 500mm (Approx)
Height : 1500mm (Approx.)
Weight : 65kg (Approx.)
Power : AC 220V, 50/60Hz. (110V on request)

ACCESSORIES at EXTRA COST:-
1. Beam Splitter with Camera Mount
2. CCD Camera for Live View
3. Motorized Foot Control system
4. LED Monitor
